SENZEMan

28”

SENZE Man matt deep blue pearl

2 099.99 EUR 2 399.99 EUR

Sale

2024

Details
Specification
Komponenty
Technologies
Size
Geometry

Details

Specification

Year

2024

Engine

BAFANG M500 / 250W / 95Nm

Battery

CTM IGB 720Wh / 48V / 15Ah

Frame

ALU 6061, M (17"), L (19"), XL (21")

Fork

Suntour XCM32 ATB 80mm

Shifting

Shimano CUES SL-U4000/9sp.

Derailleur

Shimano CUES RD-U4000

Freewheel

Shimano CUES CS-LG300/9, 11-46

Chainwheel

Bafang 42T, 170mm

Brakes

Shimano MT200 / SMRT10M

Rim

WTB ST i23 TCS 2.0 29" 36H

Tires

WTB Riddler 700x45C Comp

Hubs

Novatec D041DSB/D142TSE,36H ,CL

Pedals

VPE 537

Chain

Shimano CN-LG500

Stem

CTM UNO/70mm

Handlebars

CTM rise bar, 700/31,8 mm

Head set

NECO H153

Saddle

SR Vivo Ergo Man

Seat post

CTM 350x31,6 mm

Speed

9 speed

* Product specification, description and products themselves can be changed without further notice to improve their function, reliability or design

COMPONENTS

Engine
Bafang M500

Bafang - world famous electric motor manufacturer with over 20 years of experience and one of the most popular M500 motors. With an enormous 95Nm of torque, it provides consistent, powerful and efficient support to tackle any terrain. The motor is equipped with a torsion (pressure) sensor whereby the control unit evaluates how hard the rider is pedalling and accordingly ensures a perfectly tuned and responsive performance. You can choose from 5 levels of assistance and there is also a "walking assist" mode. With this versatile, affordable, lightweight (3.4kg) and, most importantly, powerful motor, you'll have loads of endless fun.

Battery
630 Wh integrated battery

One of the biggest advantages of this bike is certainly the battery with a capacity of up to 720Wh (15 Ah), allowing a potential range of up to 150 km on a single charge - the total range can vary depending on the level of support used and the nature of the route. The battery uses high quality Li-ion SAMSUNG cells and the time to full charge is approximately 5-7 hours.

Display
BAFANG

Clarity, amount of information displayed and a 3.5 inch full colour LCD Matrix screen - this is a brief summary of the main advantages of the Bafang DP-C18. A useful benefit is certainly the USB output, through which you can charge your smartphone. The weight of the display is only 200g, it uses the CAN protocol for communication and it also has IPX5 water resistance. On the backlit display you will of course find all the necessary information about your ride - speed (current, average, maximum), battery status, selected support mode, range, distance travelled, etc.

Remote control
BAFANG

You control all the functions of the e-bike via the remote control located on the handlebars of the bike so that everything is conveniently within your reach. Starting up, changing the assistance mode, switching lights on/off and changing information on the display are all instantly at your fingertips. Of course, the control position can be adjusted for your comfort

INFINI
Integrated lighting

The high-quality light from INFINI with 150 lumens provides excellent performance and contributes to your safety. It can be conveniently operated directly from the electric drive control. The tail light shines a bright red colour that is visible from a long distance. Thanks to its design, the light is not only visible from behind but also from the sides which further increases your safety when driving on the road.

Bicycle size

200 cm

190 cm

180 cm

170 cm

160 cm

150 cm

160-175 cm

175-185 cm

185-205 cm

* Above sizes are only suggested. We strongly recommend to check before buy.

Geometry

		XL (21")
A	Head tube angle	69.00
B	Seat tube angle	74.00
C	Horizontal top tube	620.00 mm
D	Seat tube length	533.00 mm
E	Chainstay length	475.00 mm
F	Front center	694.80 mm
G	Head tube length	160.00 mm
H	BB drop	-60.00
I	Fork length	462.00 mm
J	Fork offset	38.00 mm
K	Wheelbase	1164.00 mm

TECHNOLÓGIE

Hydraulické brzdy

AL6061

Uzamykanie odpruženej vidlice

Powder coating

Hydraulické brzdy

Hydraulické brzdy sú suverénne najspoľahlivejším a zároveň aj najúčinnejším spôsobom ako ubrzdiť bicykel za všetkých podmienok.

AL6061

Zliatina hliníku je vďaka prímesiam ľahšia a konštruktérom umožňuje vyššiu tvarovateľnosť pri navrhovaní rámov ako rada 700x. Výhodou je jej dostupnosť a nižšia cena.

Uzamykanie odpruženej vidlice

Uzamykanie odpruženej vidlice je hydraulický systém, ktorý uzatvorí prietok oleja, čím zabráni nežiaducemu pruženiu v pohybe. Mechanický systém jednoducho zamkne pružinu. Vhodné pri silovom šliapaní, alebo presunoch po asfalte.

Powder coating

Povrchová úprava špecifická nanášaním elektrostatických prachových častíc farby. Výsledkom je odolná a veľmi trvácna povrchová úprava rámu.
