| M | L | XL |
M
L
XL
|
||
|---|---|---|---|---|---|
| A | Head tube angle | 69.00 | 69.00 | 69.00 | |
| B | Seat tube angle | 73.00 | 73.00 | 73.00 | |
| C | Horizontal top tube | 590.00 mm | 610.00 mm | 635.00 mm | |
| D | Seat tube length | 406.00 mm | 457.00 mm | 508.00 mm | |
| E | Chainstay length | 430.00 mm | 430.00 mm | 430.00 mm | |
| F | Front center | 661.00 mm | 682.00 mm | 707.00 mm | |
| G | Head tube length | 105.00 mm | 110.00 mm | 120.00 mm | |
| H | BB drop | -48.00 | -48.00 | -48.00 | |
| I | Fork length | 505.00 mm | 505.00 mm | 505.00 mm | |
| J | Fork offset | 38.00 mm | 38.00 mm | 38.00 mm | |
| K | Wheelbase | 1087.00 mm | 1107.00 mm | 1133.00 mm |
