| 520 | 540 | 560 | 580 | 600 |
520
540
560
580
600
|
||
|---|---|---|---|---|---|---|---|
| A | Head tube angle | 70.00 | 71.00 | 72.00 | 73.00 | 74.00 | |
| B | Seat tube angle | 73.00 | 73.00 | 73.00 | 73.00 | 73.00 | |
| C | Horizontal top tube | 525.00 mm | 545.00 mm | 558.00 mm | 580.00 mm | 600.00 mm | |
| D | Seat tube length | 440.00 mm | 480.00 mm | 500.00 mm | 540.00 mm | 560.00 mm | |
| E | Chainstay length | 430.00 mm | 430.00 mm | 430.00 mm | 430.00 mm | 430.00 mm | |
| F | Front center | 600.00 mm | 610.00 mm | 623.00 mm | 646.00 mm | 667.00 mm | |
| G | Head tube length | 140.00 mm | 140.00 mm | 150.00 mm | 175.00 mm | 185.00 mm | |
| H | BB drop | -69.00 | -69.00 | -69.00 | -69.00 | -69.00 | |
| I | Fork length | 395.00 mm | 395.00 mm | 395.00 mm | 395.00 mm | 395.00 mm | |
| J | Front center | 55.00 mm | 55.00 mm | 55.00 mm | 55.00 mm | 55.00 mm | |
| K | Wheelbase | 1020.00 mm | 1030.00 mm | 1044.00 mm | 1067.00 mm | 1088.00 mm | |
| R | Reach | 361.00 mm | 380.00 mm | 390.00 mm | 405.00 mm | 422.00 mm | |
| S | Stack height | 553.00 mm | 557.00 mm | 566.00 mm | 590.00 mm | 600.00 mm |
