| M (17") | L (18") | XL (19") |
M (17")
L (18")
XL (19")
|
||
|---|---|---|---|---|---|
| A | Head tube angle | 64.50 | 64.50 | 64.50 | |
| B | Seat tube angle | 74.00 | 74.00 | 74.00 | |
| C | Horizontal top tube | 610.00 mm | 633.00 mm | 653.00 mm | |
| D | Seat tube length | 430.00 mm | 460.00 mm | 490.00 mm | |
| E | Chainstay length | 466.00 mm | 466.00 mm | 466.00 mm | |
| F | Front center | 803.00 mm | 827.00 mm | 847.00 mm | |
| G | Head tube length | 130.00 mm | 140.00 mm | 140.00 mm | |
| H | BB drop | -25.00 | -25.00 | -25.00 | |
| I | Fork length | 575.00 mm | 575.00 mm | 575.00 mm | |
| J | Front center | 44.00 mm | 44.00 mm | 44.00 mm | |
| K | Wheelbase | 1268.50 mm | 1292.00 mm | 1312.00 mm | |
| R | Reach | 460.00 mm | 480.00 mm | 500.00 mm | |
| S | Stack height | 642.00 mm | 651.00 mm | 651.00 mm |
