| 520 | 540 | 560 | 580 | 600 |
520
540
560
580
600
|
||
|---|---|---|---|---|---|---|---|
| A | Head tube angle | 73.00 | 73.00 | 73.00 | 73.00 | 73.00 | |
| B | Seat tube angle | 73.00 | 73.00 | 73.00 | 73.00 | 73.00 | |
| C | Horizontal top tube | 525.00 mm | 545.00 mm | 560.00 mm | 580.00 mm | 595.00 mm | |
| D | Seat tube length | 450.00 mm | 500.00 mm | 520.00 mm | 540.00 mm | 560.00 mm | |
| E | Chainstay length | 405.00 mm | 405.00 mm | 405.00 mm | 405.00 mm | 405.00 mm | |
| F | Front center | 560.00 mm | 580.00 mm | 595.00 mm | 605.00 mm | 614.00 mm | |
| G | Head tube length | 140.00 mm | 140.00 mm | 155.00 mm | 175.00 mm | 195.00 mm | |
| H | BB | -69.00 | -69.00 | -69.00 | -69.00 | -69.00 | |
| I | Fork length | 375.00 mm | 375.00 mm | 375.00 mm | 375.00 mm | 375.00 mm | |
| J | Fork offset | 45.00 mm | 45.00 mm | 45.00 mm | 45.00 mm | 45.00 mm | |
| K | Wheelbase | 955.00 mm | 975.00 mm | 990.00 mm | 1001.00 mm | 1013.00 mm | |
| R | Reach | 363.00 mm | 383.00 mm | 393.00 mm | 402.00 mm | 406.00 mm | |
| S | Stack height | 548.00 mm | 548.00 mm | 563.00 mm | 582.00 mm | 601.00 mm |
