| M (17") | L (19") | XL (21") |
M (17")
L (19")
XL (21")
|
||
|---|---|---|---|---|---|
| A | Head tube angle | 71.00 | 71.00 | 71.00 | |
| B | Seat tube angle | 74.00 | 74.00 | 74.00 | |
| C | Horizontal top tube | 602.00 mm | 612.00 mm | 622.00 mm | |
| D | Seat tube length | 432.00 mm | 483.00 mm | 533.00 mm | |
| E | Chainstay length | 450.00 mm | 450.00 mm | 450.00 mm | |
| F | Front center | 660.00 mm | 670.00 mm | 680.00 mm | |
| G | Head tube length | 130.00 mm | 140.00 mm | 140.00 mm | |
| H | BB | -60.00 | -60.00 | -60.00 | |
| I | Fork length | 472.00 mm | 472.00 mm | 472.00 mm | |
| J | Fork offset | 38.00 mm | 38.00 mm | 38.00 mm | |
| K | Wheelbase | 1103.00 mm | 1114.00 mm | 1123.00 mm |
