| L | XL |
L
XL
|
||
|---|---|---|---|---|
| A | Head tube angle | 67.00 | 67.00 | |
| B | Seat tube angle | 73.00 | 73.00 | |
| C | Horizontal top tube | 641.00 mm | 667.00 mm | |
| D | Seat tube length | 457.00 mm | 510.00 mm | |
| E | Chainstay length | 440.00 mm | 440.00 mm | |
| F | Front center | 753.00 mm | 780.00 mm | |
| G | Head tube length | 115.00 mm | 120.00 mm | |
| H | BB | -50.00 | -50.00 | |
| I | Fork length | 545.00 mm | 545.00 mm | |
| J | Fork offset | 51.00 mm | 51.00 mm | |
| K | Wheelbase | 1188.00 mm | 1215.00 mm | |
| R | Reach | 445.00 mm | 470.00 mm | |
| S | Stack height | 640.00 mm | 645.00 mm |
