| M | L | XL |
M
L
XL
|
||
|---|---|---|---|---|---|
| A | Head tube angle | 66.00 | 66.00 | 66.00 | |
| B | Seat tube angle | 72.00 | 72.00 | 72.00 | |
| C | Horizontal top tube | 577.00 mm | 606.00 mm | 633.00 mm | |
| D | Seat tube length | 440.00 mm | 480.00 mm | 520.00 mm | |
| E | Chainstay length | 435.00 mm | 435.00 mm | 435.00 mm | |
| F | Front center | 730.00 mm | 760.00 mm | 787.00 mm | |
| G | Head tube length | 95.00 mm | 110.00 mm | 115.00 mm | |
| H | BB | -50.00 | -50.00 | -50.00 | |
| I | Fork length | 545.00 mm | 545.00 mm | 545.00 mm | |
| J | Fork offset | 51.00 mm | 51.00 mm | 51.00 mm | |
| K | Wheelbase | 1160.00 mm | 1191.00 mm | 1218.00 mm | |
| R | Reach | 420.00 mm | 445.00 mm | 470.00 mm | |
| S | Stack height | 616.00 mm | 630.00 mm | 635.00 mm |
